Nanchang RuiGu Hotel：Wooden Acoustic Partition Wall with 304 Stainless Steel Roller and 6061-T6 Profile for Up to 18M Height

Nama merek:	AE
Nomor Model:	AE100
Moq:	10 meter persegi
harga:	USD 80-108 Per Square Meter
Ketentuan Pembayaran:	L/C, D/A, D/P, T/T, Western Union, Moneygram
Kemampuan Penyediaan:	1000 meter persegi per bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Guangdong, Cina

Sertifikasi:

ISO9001 SGS

Nama Produk:

Pengecualian Akustik Kayu Wa

Aplikasi:

Ruang Konferensi, Aula Perjamuan

Opsi finishing:

Bahan yang disediakan pelanggan

Tinggi:

Hingga 18 juta

Desain:

OEM & ODM

Isolasi suara:

Max 56db

Kemasan rincian:

Lapisan busa dan kardus keras dengan kotak kayu lapis atau palet baja

Menyoroti:

Up to 18M Height Acoustic Partition Wall

304 Stainless Steel Roller Sliding Partition Wall

6061-T6 Profile Room Divider

Deskripsi Produk

Meeting Room Wooden Acoustic Partition Wall Sliding Ceiling Panels Customized

Premium Acoustic Partition Walls

Our acoustic partition walls, also known as sliding folding partitions or room dividers, are renowned worldwide for their top-tier quality, versatile design, acoustic efficiency, and enduring durability. Manufactured in China, these partitions feature a sturdy aluminum frame and come in various sizes, performance levels, and decorative finishes.

Versatile and Durable Design

We excel in producing and exporting banquet hall acoustic partition walls to international markets. Available in three different wall thicknesses, our partitions offer impressive durability and can accommodate taller structures. Choose from a broad selection of acoustic and decorative surface options tailored to your specific needs.

Outstanding Acoustic Performance

Designed to minimize sound transmission and absorption, our partitions significantly reduce acoustic reflections and improve soundproofing. They are ideal for dividing large spaces into smaller, private areas while ensuring superior sound insulation.

Efficient and Functional

Our banquet hall acoustic partition walls are part of a movable soundproof partition system that forms a flexible and removable wall. Utilizing an overhead track system, our partitions provide smooth operation and excellent soundproofing. Perfect for hotels, banquet halls, and other large venues.

Roller Options & Features

Dupont POM roller
304 stainless steel heavy duty roller with safety device & CNC machining
Unique and patented wheel surface and shape for easy operation

Panel Options & Features

Thickness: 68mm, 89mm & 105mm
Wide variety of acoustical and decorative finishes available
6061-T6 profile and inside Q235 steel frame for superior durability
Top & bottom jack lifting mechanism seal with power of 800N
Magnetic seal in concave & convex profile has magnetic attraction of 40N/m

Specifications

GEMMAN PARTITION TECHNOLOGY GLOBAL PROFESSIONAL SPACE SOLUTIONS

Series	Element thickness	Element width* (min./max.)	Clear height* (min./max.)	Framed construction	Panel fixing	Element interconnection
AE65	68	600/1,250	2,000/4,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE85	89	600/1,250	2,000/5,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE100	105	600/1,250	2,000/18,000	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips

Technology: Weighted sound reduction value determined per GB/T19889.3-2005 in Rw (dB):52/56
Positive and frictional locking of the vertical element connections: Convex-concave profile form, force of attraction of the magnetic strip 40 N/m
* Larger widths possible on application. Provisional details regarding the element heights/element widths indicated can only be confirmed following consultation with the Design Department.
