Customized Acoustic Sliding Partition Wall with Magnetic Seal and German Partition Technology SGS & ILAC-MRA Certified

Nama merek:	AE
Nomor Model:	AE85
Moq:	10 meter persegi
harga:	USD80-108Per Square Meter
Ketentuan Pembayaran:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Kemampuan Penyediaan:	1000 meter persegi per bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Guangdong, Tiongkok

Sertifikasi:

ISO9001 SGS

Produk:

Dinding Partisi Geser Akustik

Kepatuhan:

Aula perjamuan, Sekolah, Hotel

Ukuran:

Kustomisasi (tinggi: hingga 6m, lebar per panel: hingga 1,2m)

Bahan Panel:

PAPAN TAHAN API

Desain:

OEM & ODM

Isolasi suara:

Max 56db

Kemasan rincian:

Lapisan busa dan kardus keras dengan kotak kayu lapis atau palet baja

Menyoroti:

Magnetic Seal Acoustic Sliding Partition Wall

German Partition Technology Movable Partition Wall

SGS & ILAC-MRA Certified Room Divider

Deskripsi Produk

Customized Acoustic Sliding Partition Walls For Room Management

Flexible Wall Systems Sliding Acoustic Partition Wall for Room Management

Innovate your workspace with our flexible movable partitions. Perfect for open offices, these partitions help create defined work zones without compromising on style.

AE Partition is dedicated to providing clients worldwide with intelligent solutions for managing space efficiently. Our approach is holistic, encompassing everything from the planning and design stages to the installation and upkeep of movable partition wall systems. By offering high-quality services that ensure the longevity and performance of our products, AE Partition stands as a trusted partner in room management.

Our Strengths

Quick follow up with quote
Site inspections
Identification of potential safety or function issues
Experience in doing project with heavy customers
Delivery time control for decent orders
Designing team for new products & solutions development
The performance of the product is certified by SGS & ILAC-MRA
German Partition Technology & Global Professional Space Solutions
Increase the Longevity of Your Specialty Products

Roller Option & Feature

Dupont POM roller
304 stainless steel heavy duty roller with safety device & CNC machining
Unique and patented wheel surface and shape make the whole movable partition easy to use

Panel Option & Feature

Thickness: 68mm & 89mm & 105mm
Wide variety of acoustical and decorative finishes available
6061-T6 profile and inside Q235 steel frame for superior durability
Top & bottom jack lifting mechanism seal are with power of 800N. Magnetic seal in concave & convex profile has magnetic attraction of 40N/m

Specification

Series	Element thickness	Element width* (min./max.)	Clear height* (min./max.)	Framed construction	Panel fixing	Element interconnection/design of the vertical profiles
AE65	68	600/1,250	2,000/4,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE85	89	600/1,250	2,000/5,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE100	105	600/1,250	2,000/18,000	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips

Technology: Weighted sound reduction value determined per GB/T19889.3-2005 in Rw (dB):52/56

Positive and frictional locking: Convex-concave profile form, force of attraction of the magnetic strip 40 N/m

* Larger widths possible on application. Provisional details regarding the element heights/element widths indicated can only be confirmed following consultation with the Design Department.
