rincian produk

Rumah Produk

Sliding Single Glazed Office Glass Partition Wall with Concealed Connections and Transparent Coloured Glass

Nama merek:	AE
Nomor Model:	Sistem panorama EGG-100C
Moq:	10 meter persegi
harga:	USD112-145Per Square Meter
Ketentuan Pembayaran:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Kemampuan Penyediaan:	1000 meter persegi per bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Guangdong, Tiongkok

Sertifikasi:

ISO9001 SGS

Nama Produk:

Partisi Kaca Kaca Tunggal

Aplikasi:

Kantor, Aula, Ruang Rapat, dan sebagainya

Standar Produksi:

Berdasarkan gambar kerja yang telah disetujui oleh pembeli

profil partisi gantung:

paduan aluminium, strip PVC, dinding partisi kedap suara

kaca partisi gantung:

kaca tempered bening, kaca buram, kaca terukir asam

Desain:

OEM & ODM

Isolasi Suara:

30-42dB

Kemasan rincian:

lapisan busa dan karton keras dengan kotak kayu lapis

Menyoroti:

Concealed Connections Glass Partition Wall

Transparent Office Glass Partition Wall

Coloured Single Glazed Glass Partition

Deskripsi Produk

Sliding Single Glazed Frame Office Glass Partition Wall For Exhibition Centers

Our Single Glazed Frame Office Glass Partition Wall System offers a sleek and space-efficient solution for modern office environments. When stacked, the elements compactly arrange into a minimal footprint, making them ideal for tight spaces. The lightweight nature of these elements provides notable structural benefits, enhancing ease of use and installation.

The system features four standard stacking and parking track options, ensuring smooth and quiet operation. The individual glass panels slide seamlessly into place on the movable and operable partition tracks, offering both convenience and minimal noise disruption. Ideal for dynamic office spaces, this system combines functionality with sophisticated design.

Operation

Partitions are top-supported, manually operated panels stacked in designated areas. When closed, the operable wall provides a complete sound retardant barrier without requiring floor tracks.

Specification

Technical Characteristics	Details
Wall Thickness	108mm/90mm
Height	Up to 3000mm
Grid Width	Up to 1200mm
Weight	70-80kg/sq.m
Attachment to Building Structure	Concealed connections to the slab and walls; sealing along the perimeter; deviations ±10mm in height and width
Glass Thickness	10mm/12mm tempered
Visibility Options	Transparent, coloured, matte glass; between-the-glass blinds; foil, screen printing, enamel
Description	Glazed partition with an in-plane streamlined look. Made from aluminium, double-glazing structurally adhered to the profiles.

Project Examples

Our Services
