Customized Movable Soundproof Partition with Fabric Finish and 6061-T6 Profiles

Nama merek:	AE
Nomor Model:	AE85
Moq:	10 meter persegi
harga:	USD70-119 Per Square Meter
Ketentuan Pembayaran:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Kemampuan Penyediaan:	1000 meter persegi per bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Guangdong, Tiongkok

Sertifikasi:

ISO9001 SGS

Seri:

dinding partisi kantor kedap suara

Aplikasi:

Aula perjamuan, Ruang konferensi

Papan dasar:

Papan laminasi tekanan tinggi

Ukuran:

Kustomisasi (tinggi: hingga 6m, lebar per panel: hingga 1,2m)

Desain:

OEM & ODM

Isolasi suara:

Maks 52dB

Kemasan rincian:

Lapisan busa dan kardus keras dengan kotak kayu lapis atau palet baja

Menyoroti:

6061-T6 Profiles Soundproof Partition

Q235 Steel Frame Movable Partition Wall

Fabric Finish Office Partition

Deskripsi Produk

Movable Soundproof Office Partition Walls Customized With Fabric Finish

Best Soundproof Partition Solutions for Quiet Workspaces with fabric finish

AE Partition provides innovative solutions for efficient room management to customers worldwide. Specializing in movable partition wall systems, AE Partition offers tailored designs that meet the unique requirements of any space. From small offices to large conference centers, our adaptable partitions seamlessly integrate with existing architecture to create flexible environments that promote productivity and aesthetic appeal.

Our Advantages

The performance of the product is certified by SGS & ILAC-MRA
German Partition Technology & Global Professional Space Solutions
Increase the Longevity of Your Specialty Products
Quick follow up with quote
Site inspections
Identification of potential safety or function issues
Your inquiry related to our products or prices will be in 24 hours
Well-trained and experienced staff to answer all your inquiries in Fluent English
We can follow your design to produce

Roller Options & Advantages

Dupont POM Rollers: Designed for high performance and durability.
304 Stainless Steel Heavy-Duty Rollers: Equipped with safety devices and CNC precision for robust functionality.
Patented Wheel Design: Unique surface and shape ensure smooth and easy movement across the partition system.

Panel Options & Advantages

Versatile Thickness Choices: Available in 68mm, 89mm, and 105mm to accommodate different acoustic and structural requirements.
Wide Finish Selection: A diverse range of acoustical and decorative finishes to suit various design aesthetics.
Sturdy Construction: Crafted with 6061-T6 profiles and an internal Q235 steel frame for enhanced durability.
Advanced Sealing Mechanism: Jack lifting seals deliver 800N of force, while magnetic seals provide 40N/m of magnetic attraction for superior performance.

Specification

Series	Element thickness	Element width* (min./max.)	Clear height* (min./max.)	Framed construction	Panel fixing	Element interconnection/design of the vertical profiles
AE65	68	600/1,250	2,000/4,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE85	89	600/1,250	2,000/5,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE100	105	600/1,250	2,000/18,000	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips

Technology:
Weighted sound reduction value determined per GB/T19889.3-2005 in Rw (dB):52/56
Positive and frictional locking of the vertical element connections: Convex-concave profile form, force of attraction of the magnetic strip 40 N/m
* Larger widths possible on application. Provisional details regarding the element heights/element widths indicated can only be confirmed following consultation with the Design Department.
** Depending on the sound insulation/weight
