304 Stainless Steel Movable Partition Wall with 6061-T6 Profile and Q235 Steel Frame for Auditorium Conference Rooms

Nama merek:	AE
Nomor Model:	AE100
Moq:	10 meter persegi
harga:	USD 90-125 Per Square Meter
Ketentuan Pembayaran:	L/C, D/A, D/P, T/T, Western Union, Moneygram
Kemampuan Penyediaan:	1000 meter persegi per bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Guangdong, Cina

Sertifikasi:

ISO9001 SGS

Nama Produk:

Dinding Pembagian Ruang Konferensi

Kepatuhan:

Ruang pertemuan, sekolah

Ketebalan:

105cm

Peringkat STC:

42-56dB

Ukuran:

Kustomisasi (Tinggi: hingga 18M, Lebar per Panel: hingga 1,2M)

Kemasan rincian:

Lapisan busa dan kardus keras dengan kotak kayu lapis atau palet baja

Menyoroti:

304 Stainless Steel Movable Partition Wall

6061-T6 Profile Movable Partition Wall

Q235 Steel Frame Movable Partition Wall

Deskripsi Produk

Auditorium Conference Room Partition Wall - Portable Folding And Removable Partition Wall

The Movable Partition Wall effortlessly transforms spaces with its slim, single-thickness 100 mm sliding panels, dividing rooms in mere minutes. Unlike traditional setups, no heavy beams or ceiling bracing are necessary; instead, the lightweight top guide track can be directly mounted to a suspended ceiling. The floor track is easily removable, ensuring an unobstructed floor when the room divider is not in use.

This Movable Acoustic Wall excels in sound insulation, offering a superior range of 37-53 decibels, making it the premier choice for noise reduction. Operated smoothly on ball-bearing trolleys, the Movable Wall Panels are not only easy to maneuver but also feature robust construction with integrated safety mechanisms, ensuring reliable and secure operation.

High-Quality Service Commitment

Our products are certified by SGS and ILAC-MRA, ensuring reliable performance.
We combine leading German partition technology to provide global professional space solutions.
Extend the lifespan of your professional products, ensuring long-term performance stability.
Provide quick follow-up and transparent quoting services to meet your needs.
Offer on-site inspection services to ensure quality and accuracy during project implementation.
We promise punctual delivery to ensure smooth project progress according to schedule.

Unique Roller Options & Features

Utilizes Dupont POM rollers for optimal performance.
Crafted from 304 stainless steel with heavy-duty capabilities, incorporating safety features and precision CNC machining.
Patented wheel design ensures effortless operation of the entire movable partition system.

Panel Options & Features

Thickness: 100mm for enhanced stability and sound insulation.
Offers a diverse range of acoustical and decorative finishes to suit various design preferences.
Constructed with a robust 6061-T6 profile and a Q235 steel frame inside for exceptional durability.
Features top and bottom jack lifting mechanisms with a sealing power of 800N. The magnetic seal with concave and convex profiles provides a magnetic attraction of 40N/m, ensuring secure closure and acoustic insulation.

Specification

GEMMAN PARTITION TECHNOLOGY GLOBAL PROFESSIONAL SPACE SOLUTIONS

Dimensions in mm*	Design
Series	Element thickness
AE65	68
AE85	89
AE100	105
Technology: Weighted sound reduction value determined per GB/T19889.3-2005 in Rw (dB):52/56 Positive and frictional locking of the vertical element connections: Convex-concave profile form, force of attraction of the magnetic strip 40 N/m * Larger widths possible on application. Provisional details regarding the element heights/element widths indicated can only be confirmed following consultation with the Design Department.
