Customizable Movable Partition Wall with 68CM Thickness and 800N Sealing Power Operable Wall System

Name: Customizable Movable Partition Wall with 68CM Thickness and 800N Sealing Power Operable Wall System
Brand: FOSHAN AE PARTITION TECHNOLOGY LIMITED COMPANY
SKU: AE65
Price: 93.00 USD
Availability: InStock

Nama merek:	AE
Nomor Model:	AE65
Moq:	10 meter persegi
harga:	USD 79-108 per square meter
Ketentuan Pembayaran:	T/T, L/C, Western Union
Kemampuan Penyediaan:	1000 meter persegi per bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Guangdong, Tiongkok

Sertifikasi:

ISO9001 SGS CANS

Seri:

Dinding Partisi Bergerak AE65

Opsi finishing:

Bahan yang disediakan pelanggan

Aplikasi:

Restoran, Ruang Pertemuan

Ketebalan:

68cm

Peringkat STC:

42-56dB

Ukuran:

Kustomisasi (Tinggi: hingga 4,5M, Lebar per Panel: hingga 1,2M)

Nama:

Tembok Pembagian yang Bisa Dipindahkan

Kemasan rincian:

Lapisan busa dan kardus keras dengan kotak kayu lapis atau palet baja

Menyoroti:

68CM Thickness Movable Partition Wall

800N Sealing Power Operable Wall System

40N/m Magnetic Attraction Room Divider

Deskripsi Produk

Customizable Movable Partition Wall Office Operable Wall Systems

AE operable partitions are a series of panels suspended from tracks with high quality, functionality and variability for room-dividing and multifunctional layout configuration.

Key Features

German Partition Technology Global Professional Space Solutions
Highly competitive prices
Good quality control
Smooth communication
State-of-art technology products
Effective OEM&ODM service

Roller Options & Features

Dupont POM roller
304 stainless steel heavy duty roller with safety device & CNC machining
Unique and patented wheel surface and shape for easy operation

Panel Options & Features

Thickness: 68mm, 89mm & 105mm options
Wide variety of acoustical and decorative finishes available
6061-T6 profile with Q235 steel frame for superior durability
Top & bottom jack lifting mechanism seal with 800N power
Magnetic seal in concave & convex profile with 40N/m magnetic attraction

Technical Specifications

Series	Element Thickness (mm)	Element Width (mm)*	Clear Height (mm)*	Construction	Panel Fixing	Element Interconnection
AE65	68	600/1,250	2,000/4,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE85	89	600/1,250	2,000/5,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE100	105	600/1,250	2,000/18,000	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips

Technical Details

Weighted sound reduction value: 52/56 dB (Rw) per GB/T19889.3-2005
Positive and frictional locking of vertical element connections
Convex-concave profile form with magnetic strip attraction force of 40 N/m

* Larger widths possible on application. Provisional details regarding element heights/widths require consultation with Design Department.
